Defining templates

Templates are defined in template descriptor files as a JSON array:

[
{
"$schema": "https://unpkg.com/@camunda/zeebe-element-templates-json-schema/resources/schema.json",
"name": "Template 1",
"id": "sometemplate",
"description": "some description",
"version": 1,
"appliesTo": [
"bpmn:Task"
],
"elementType": {
"value": "bpmn:ServiceTask",
},
"properties": [
...
]
},
{
"name": "Template 2",
...
}
]

As seen in the code snippet, a template consists of a number of important components:

  • $schema : String: URI pointing towards the JSON schema which defines the structure of the element template .json file. Element template schemas are maintained in the element templates JSON schema repository. Following the JSON schema standard, you may use them for validation or to get assistance (e.g., auto-completion) when working with them in your favorite IDE.
note

The $schema attribute is required for Camunda 8 element templates.

Example:

"$schema": "https://unpkg.com/@camunda/zeebe-element-templates-json-schema/resources/schema.json"
  • name : String: Name of the template. Shown in the element template selection modal and in the properties panel (after applying an element template).
  • id : String: ID of the template.
  • description : String: Optional description of the template. Shown in the element template selection modal and in the properties panel (after applying an element template).
  • documentationRef : String: Optional URL pointing to a template documentation. Shown in the properties panel (after applying an element template).
  • version : Integer: Optional version of the template. If you add a version to a template, it is considered unique based on its ID and version. Two templates can have the same ID if their version is different.
  • appliesTo : Array<String>: List of BPMN types the template can be applied to.
  • elementType : Object: Optional type of the element. If you configure elementType on a template, the element is replaced with the specified type when a user applies the template.
  • properties : Array<Object>: List of properties of the template.

Creating and editing Connector templates

Connector templates are a specific kind of element template. You can edit them with visual preview and edit support like formatting, code completion, and error highlighting in Web Modeler.

JSON schema compatibility

The application uses the $schema property to ensure compatibility for a given element template. You find the latest supported versions here.

The tooling ignores element templates defining a higher $schema version and logs a warning message.

For example, given the following $schema definition, the application takes 0.9.1 as the JSON schema version of the element template:

"$schema": "https://unpkg.com/@camunda/zeebe-element-templates-json-schema@0.9.1/resources/schema.json"

The JSON schema versioning is backward-compatible, meaning that all versions including or below the current one are supported.

Supported BPMN types

Currently, element templates may be used on the following BPMN elements:

  • bpmn:Activity (including tasks, service tasks, and others)
  • bpmn:SequenceFlow (for maintaining condition)
  • bpmn:Process
  • bpmn:Event

Defining template properties

With each template, you define some user-editable fields as well as their mapping to BPMN 2.0 XML, and Camunda extension elements.

Let us consider the following example that defines a template for a mail sending task:

{
"$schema": "https://unpkg.com/@camunda/zeebe-element-templates-json-schema/resources/schema.json",
"name": "REST Connector",
"id": "io.camunda.examples.RestConnector",
"description": "A REST API invocation task.",
"appliesTo": ["bpmn:ServiceTask"],
"properties": [
{
"type": "Hidden",
"value": "http",
"binding": {
"type": "zeebe:taskDefinition",
"property": "type"
}
},
{
"label": "REST Endpoint URL",
"description": "Specify the url of the REST API to talk to.",
"type": "String",
"binding": {
"type": "zeebe:taskHeader",
"key": "url"
},
"constraints": {
"notEmpty": true,
"pattern": {
"value": "^https?://.*",
"message": "Must be http(s) URL."
}
}
},
{
"label": "REST Method",
"description": "Specify the HTTP method to use.",
"type": "Dropdown",
"value": "get",
"choices": [
{ "name": "GET", "value": "get" },
{ "name": "POST", "value": "post" },
{ "name": "PATCH", "value": "patch" },
{ "name": "DELETE", "value": "delete" }
],
"binding": {
"type": "zeebe:taskHeader",
"key": "method"
}
},
{
"label": "Request Body",
"description": "Data to send to the endpoint.",
"value": "",
"type": "String",
"optional": true,
"binding": {
"type": "zeebe:input",
"name": "body"
}
},
{
"label": "Result Variable",
"description": "Name of variable to store the response data in.",
"value": "response",
"type": "String",
"optional": true,
"binding": {
"type": "zeebe:output",
"source": "= body"
}
}
]
}

The example defines five custom fields, each mapped to different technical properties:

  • The task type http is mapped to the type property of a zeebe:taskDefinition element in BPMN 2.0 XML.
  • The REST Endpoint URL and REST Method are mapped to task headers.
  • The Request Body is mapped to a local variable via an input parameter.
  • The Result Variable is mapped into a process variable via an output parameter.

The task type is hidden to the user. Properties specified in the template can be edited through the properties panel as shown in the following screenshot:

Custom Fields

As seen in the example, the important attributes in a property definition are:

  • label: A descriptive text shown with the property.
  • type: Defining the visual appearance in the properties panel (may be any of String, Text, Boolean, Dropdown or Hidden).
  • value: An optional default value to be used if the property to be bound is not yet set.
  • binding: Specifying how the property is mapped to BPMN or Camunda extensions (cf. bindings).
  • constraints: A list of editing constraints to apply to the template.

In addition, fields can be activated conditionally via these properties:

  • id: An identifier that can be used to reference the property in conditional properties
  • condition: A condition that determines when the property is active

Generated value

As an alternative to static value, you can use a generated value. The value is generated when a property is applied to an element. Currently, the generated value can be a UUID:

{
"type": "Hidden",
"generatedValue": {
"type": "uuid"
},
"binding": {
"type": "zeebe:property",
"name": "id"
}
}

Types

The input types String, Text, Number, Boolean, Dropdown, and Hidden are available. As seen above, String maps to a single-line input, while Text maps to a multi-line input.

Number type

The Number type maps to a number input field. By default, this will be persisted as a string in the BPMN. Refer to the FEEL section to use Numbers as expressions.

Boolean / checkbox type

The Boolean type maps to a checkbox that can be toggled by the user.

When checked, it maps to true in the respective field (refer to bindings). Additionally, refer to the FEEL section to use Booleans as expressions.

The Dropdown type allows users to select from a number of pre-defined options that are stored in a custom properties choices attribute as { name, value } pairs:

...
"properties": [
...
{
"label": "REST Method",
"description": "Specify the HTTP method to use.",
"type": "Dropdown",
"value": "get",
"choices": [
{ "name": "GET", "value": "get" },
{ "name": "POST", "value": "post" },
{ "name": "PATCH", "value": "patch" },
{ "name": "DELETE", "value": "delete" }
],
"binding": {
"type": "zeebe:taskHeader",
"key": "method"
}
}
]
...

The resulting properties panel control looks like this:

properties panel drop down

FEEL

The following input types support the feel property:

  • String
  • Text
  • Number
  • Boolean
FEEL required

The field will be displayed as a FEEL editor and a visual indication that a FEEL expression is required will be shown:

  "properties": [
{
"label": "Required FEEL Expression",
"type": "String",
"feel": "required"
}
]
FEEL optional

An indicator to switch to a FEEL expression is shown. When activated, the field will be displayed as a FEEL editor:

  "properties": [
{
"label": "Optional FEEL Expression",
"type": "String",
"feel": "optional"
}
]

For Boolean and Number fields, the value will always be persisted as a FEEL expression. This ensures that the value will not be interpreted as a string when evaluated in the engine.

FEEL static

The value of feel: static is only valid for Boolean and Number fields. Similar to FEEL optional, the value of the field will be persisted as a FEEL expression. However, there is no toggle to switch to a FEEL editor and ensures only a static value can be entered:

  "properties": [
{
"label": "Static FEEL value",
"type": "Number",
"feel": "static"
}
]

Bindings

The following ways exist to map a custom field to the underlying BPMN 2.0 XML. The mapping result in the following section uses [userInput] to indicate where the input provided by the user in the Properties Panel is set in the BPMN XML. As default or if no user input was given, the value specified in value is displayed and used for [userInput]. [] brackets are used to indicate where the parameters are mapped to in the XML.

Notice that adherence to the following configuration options is enforced by design. If not adhering, it logs a validation error and ignores the respective element template.

property

Binding typeproperty
Valid property type'sAll property types are supported
Binding parametersname: The name of the property
Mapping result<... [name]=[userInput] ... />

Configures a generic BPMN element property.

zeebe:input

Binding typezeebe:input
Valid property type'sString
Text
Hidden
Dropdown
Binding parametersname: The name of the input parameter
Mapping result<zeebe:input target="[name]" source="[userInput] />

Configures an input mapping.

zeebe:output

Binding typezeebe:output
Valid property type'sString
Text
Hidden
Dropdown
Binding parameterssource: The source of the output parameter
Mapping result<zeebe:output target="[userInput]" source="[source] />

Configures an output mapping.

zeebe:taskHeader

Binding typezeebe:taskHeader
Valid property type'sString
Text
Hidden
Dropdown
Binding parameterskey: The key of the task header
Mapping result<zeebe:header key="[key]" value="[userInput] />

Configures a task header.

zeebe:taskDefinition

Binding typezeebe:taskDefinition
Valid property type'sString
Text
Hidden
Dropdown
Binding parametersproperty: The name of the task definition property. Can be type or retries.
Mapping result<zeebe:taskDefinition [property]="[userInput]" />

Configures the task for a service or user task.

zeebe:taskDefinition:type

danger

zeebe:taskDefinition:type is a deprecated binding. Instead, use zeebe:taskDefinition with property=type.

Binding typezeebe:taskDefinition:type
Valid property type'sString
Text
Hidden
Dropdown
Binding parameters
Mapping result<zeebe:taskDefinition type="[userInput]" />

Configures the task type for a service or user task.

zeebe:property

Binding typezeebe:property
Valid property type'sString
Text
Hidden
Dropdown
Binding parametersname: The name of the property
Mapping result<zeebe:property name="[name]" value="[userInput] />

The zeebe:property binding allows you to set any arbitrary property for an outside system. It does not impact execution of the Zeebe engine.

bpmn:Message#property

Binding typebpmn:Message#property
Valid property type'sString
Text
Hidden
Dropdown
Binding parametersname: The name of the property
Mapping result<bpmn:message [name]="[userInput]" />

The bpmn:Message#property binding allows you to set properties of a bpmn:Message referred to by the templated element. This binding is only valid for templates of events with bpmn:MessageEventDefinition, receive tasks, and send tasks.

bpmn:Message#zeebe:subscription#property

Binding typebpmn:Message#property
Valid property type'sString
Text
Hidden
Dropdown
Binding parametersname: The name of the property
Mapping result<zeebe:subscription [name]="[userInput]" />

The bpmn:Message#zeebe:subscription#property binding allows you to set properties of a zeebe:subscription set within bpmn:Message referred to by the templated element. This binding is only valid for templates of events with bpmn:MessageEventDefinition, and receive tasks.

note

The binding name of correlationKey is not applicable to message start events on a process. In such cases, the property is automatically hidden.

zeebe:calledElement

Binding typezeebe:calledElement
Valid property type'sString
Text
Hidden
Dropdown
Binding parametersproperty: The name of the property (only processId is supported)
Mapping result<zeebe:calledElement [property]="[userInput]" />

The zeebe:calledElement binding allows you to configure process called by a call activity.

note

For zeebe:calledElement bindings, variable propagation is not supported. To provide or retrieve variables, use zeebe:input and zeebe:output bindings.

Optional bindings

We support optional bindings that do not persist empty values in the underlying BPMN 2.0 XML.

If a user removes the value in the configured control, it will also remove the mapped element.

[
{
"$schema": "https://unpkg.com/@camunda/zeebe-element-templates-json-schema/resources/schema.json",
"name": "Task example",
"id": "some-template",
"appliesTo": ["bpmn:ServiceTask"],
"properties": [
{
"label": "Request",
"type": "String",
"optional": true,
"binding": {
"type": "zeebe:input",
"name": "request"
}
},
{
"label": "Response",
"type": "Text",
"optional": true,
"binding": {
"type": "zeebe:output",
"source": "response"
}
}
]
}
]

Supported Bindings

The following binding types can be optional:

  • zeebe:input
  • zeebe:output
  • zeebe:taskHeader
  • zeebe:property

Groups

You can define groups to organize custom fields into:

{
"$schema": "https://unpkg.com/@camunda/zeebe-element-templates-json-schema/resources/schema.json",
"name": "Groups",
"id": "group-example",
"appliesTo": [
"bpmn:ServiceTask"
],
"groups": [
{
"id": "definition",
"label": "Task definition"
},
{
"id": "request",
"label": "Request payload"
},
{
"id": "result",
"label": "Result mapping"
},
{
"id": "authentication",
"label": "Authentication",
"tooltip": "Optional authentication settings",
"openByDefault": false
}
],
"properties": [
...
]
}

Groups can have the following attributes:

  • id: Unique identifier of the group
  • label: Label of the group
  • tooltip: Tooltip for the group (optional)
  • openByDefault: Whether the group will be expanded in the properties panel (optional, default: true)

Associate a field with a group (ID) via the fields group key:

{
...
"properties": [
{
"group": "definition",
"label": "Task type",
"type": "String",
"value": "http",
"binding": {
"type": "zeebe:taskDefinition:type"
}
},
...
],
...
}

Groups

Constraints

Custom fields may have a number of constraints associated with them:

  • notEmpty: Input must be non-empty
  • minLength: Minimal length for the input
  • maxLength: Maximal length for the input
  • pattern: Regular expression to match the input against

Regular expression

Together with the pattern constraint, you can define your custom error messages:

...
"properties": [
{
"label": "Web service URL",
"type": "String",
"binding": { ... },
"constraints": {
"notEmpty": true,
"pattern": {
"value": "https://.*",
"message": "Must be https URL"
}
}
}
]

Icons

It is possible to define custom icons to update the visual appearance of elements after applying an element template.

[
{
"name": "Template 1",
"id": "sometemplate",
"appliesTo": [
"bpmn:ServiceTask"
],
"icon": {
},
"properties": [
...
]
}
]

Icons

The icon contents must be a valid data or HTTP(s) URL. We recommend using square icons as they get rendered 18x18 pixels on the canvas and 32x32 pixels in the properties panel.

Display all entries

Per default, the element template defines the visible entries of the properties panel. All other property controls are hidden. If you want to bring all the default entries back, it is possible to use the entriesVisible property.

[
{
"name": "Template 1",
"id": "sometemplate",
"entriesVisible": true,
"appliesTo": [
"bpmn:ServiceTask"
],
"properties": [
...
]
}
]

Display default entries

Defining conditional properties

Properties may have a condition which determines when they should be active, depending on the value of another property. When property is active, it is displayed in the properties panel, and its value is serialized in the XML. If a property is not active, it is not displayed, and its value is removed from the XML.

For a property value to be used in a condition, the property needs to have an id that can be referenced by the conditional property.

A property can depend on one or more conditions. If there are multiple conditions, they can be defined using allMatch. All of the conditions must be met for the property to be active.

There are three possible comparison operators:

  • equals: Checks if the value is equal to the value defined in the condition.
  • oneOf: Checks if the value is in the list of values defined in the condition.
  • isActive: Checks if the referenced property is currently active and not hidden by other conditions.
...
"properties": [
{
"id": "httpMethod",
"label": "HTTP Method",
"type": "Dropdown",
"choices": [
{ "name": "get", "value": "GET" },
{ "name": "patch", "value": "PATCH" },
{ "name": "post", "value": "POST" },
{ "name": "delete", "value": "DELETE" }
],
"binding": { ... },
},
{
"label": "Request Body",
"type": "String",
"binding": { ... },
"condition": {
"property": "httpMethod",
"oneOf": ["patch", "post", "delete"]
}
},
{
"id": "authenticationType",
"label": "Authentication Type",
"type": "Dropdown",
"choices": [
{
"name": "None",
"value": ""
},
{
"name": "Basic",
"value": "basic"
}
],
"binding": { ... }
},
{
"label": "Username",
"type": "String",
"binding": { ... },
"condition": {
"allMatch": [
{
"property": "httpMethod",
"oneOf": ["patch", "post", "delete"]
},
{
"property": "authenticationType",
"equals": "basic"
}
]
}
},
{
"label": "Password",
"type": "String",
"binding": { ... },
"condition": {
"allMatch": [
{
"property": "httpMethod",
"oneOf": ["patch", "post", "delete"]
},
{
"property": "authenticationType",
"equals": "basic"
}
]
}
},
]
