Manage your connectors

Monitor and manage connectors running on your cluster.

About connector management

With cluster connector management, you can monitor and manage running connectors on your cluster. This includes inbound connectors, such as webhooks, message queue subscriptions, and polling subscriptionsInbound connectorInbound Connectors in Camunda 8 enable workflows to receive data or messages from external systems or services, making it possible to integrate workflows into a wider business process or system architecture., and outbound connectors.

Use this feature to review connector status and troubleshoot issues. For example, you can inspect connector details and use the activity log to investigate failures.

Manage connectors

To open the Connector Management page, on the cluster Overview tab, click Manage on the Connectors component tile.

The Connector Management page provides an overview of the connectors running on a cluster.

• The page shows each connector on a separate row.
• Use this page to review connector status, inspect details, and troubleshoot issues.
• Available details depend on the connector type.

note

Webhook connector names also include the names of any connector based on the webhook. For example, "Webhook (aws:eventbridge, GitHubWebhook)".

View inbound connectors

The Inbound connectors tab shows each active inbound connector type on a separate row.

The page header shows counts across all inbound connector instances:

Field	Description
Unhealthy instances	The total number of unhealthy inbound connector instances across all connector types.
Unknown instances	The total number of inbound connector instances with an unknown status.
Total instances	The total number of inbound connector instances running.
Connector types	The number of distinct inbound connector types with active instances.

Use the search box and status filter to narrow the list of active inbound connectors. Each connector type shows aggregated counts for its instances:

Field	Description
Name	The name and type ID of the inbound connector. Select the connector name to view its running instances.
Unhealthy	The number of instances currently unhealthy.
Unknown	The number of instances with an unknown status.
Healthy	The number of instances currently healthy.
Triggers	The total number of triggers recorded for this connector type.
Correlation failed	The total number of correlation failures recorded for this connector type.

View inbound connector instances

Select an inbound connector to view its running instances.

The page header shows counts for the selected connector:

Field	Description
Active inbound executables	The number of active instances for this connector.
Triggers (total)	The total number of triggers recorded since the last runtime start.
Correlation failures (total)	The total number of correlation failures recorded since the last runtime start.

By default, the page shows each inbound connector instance on a separate row below the header counts.

Field	Description
Process	The process ID and version associated with the connector instance. Select it to open the process in Operate.
Elements	The BPMN element where the connector is active. Use this to locate the connector in your diagram.
Activated	When the connector instance was activated.
Status	The current health of the connector instance. Healthy means the connector is running without issues. Unhealthy means the connector requires attention. Open the instance details to review health details and recent activity log entries.
Restart	If a connector instance fails to activate or is stuck in an unhealthy state, select Restart after you resolve the underlying issue to retry activation.

Select Show runtime breakdown to view the header counts by runtime. The breakdown shows each runtime in its own column alongside a total:

Field	Description
Event	The type of event recorded, for example Triggered, Correlated, Correlation failed, or Activation condition not met.
Runtime	The count of this event recorded by a specific runtime deployment, identified by its deployment ID.
Total	The sum of this event's count across all runtimes.

View inbound connector instance details

Select a row to view additional details and troubleshoot issues.

The page header shows the process name and version and the BPMN element where the connector instance is active, for example Process2 v1 › Event_0sb4klr.

The page also shows the following details:

Field	Description
Instance ID	The ID of the connector instance.
Connector	The connector type ID.
Webhook URL	For webhook-based inbound connectors, the URL that triggers the connector. Select the copy icon to copy it.

Inbound connector runtimes

The page shows each runtime reporting this connector instance on a separate row.

Field	Description
Runtime	The runtime deployment reporting the connector instance.
Status	The health of the connector instance on this runtime.
Last updated	When this runtime last reported a status for the instance.

Activity log

The activity log shows recent activities recorded for the connector instance. Use these logs to troubleshoot connector issues.

Depending on the connector type, the activity log can include health changes, request details, and runtime events. The activity log redacts sensitive values where needed.

Use the filters to narrow the entries shown and toggle the sort order between latest and oldest first:

Field	Description
Tags	Filter entries by tag, for example Health.
Instance	Filter entries by a specific instance when deduplication groups multiple occurrences.
Severity	Filter entries by severity.
Time window	Filter entries recorded within a specific time range.

Activity logs are available for active connectors and recent troubleshooting. When a connector is permanently removed, its activity log entries are also removed.

Process info

For inbound connectors, this section shows detailed information about the BPMN process instance and its associated connector as a JSON object. Use this information to review process metadata, the connector template, and connector configuration properties.

For example:

[
  {
    "bpmnProcessId": "Process_0wjo4ez",
    "processName": "Order intake",
    "messageName": "order.received",
    "version": 1,
    "processDefinitionKey": 2251799813686169,
    "elementId": "StartEvent_1",
    "elementName": null,
    "elementType": "startEvent",
    "tenantId": "<default>",
    "elementTemplateDetails": {
      "id": "io.camunda.connectors.inbound.KafkaMessageStart.v1",
      "version": "6",
    },
    "properties": {
      "deduplicationMode": "AUTO",
      "deduplicationModeManualFlag": "false",
      "schemaStrategy.type": "noSchema",
      "topic.topicName": "rereer",
      "consumeUnmatchedEvents": "true",
      "inbound.type": "io.camunda:connector-kafka-inbound:1",
      "authenticationType": "credentials",
      "correlationRequired": "notRequired",
      "topic.bootstrapServers": "eererreer",
      "autoOffsetReset": "latest"
    }
  }
]

note

If you are using deduplication, each connector occurrence in the BPMN diagram is shown in the array.

View outbound connectors

The Outbound connectors tab shows each active outbound connector type on a separate row.s

The page header shows counts across all outbound connector invocations:

Field	Description
Connector types	The number of distinct outbound connector types available.
Invocations (total)	The total number of invocations recorded since the last runtime start.
Max execution time	The longest execution time recorded across all invocations.
Failure rate	The percentage of invocations that failed.

Use the search box, status filter, and With invocations checkbox to narrow the list of outbound connectors. Each connector type shows aggregated counts:

Field	Description
Name	The name and type ID of the outbound connector. Select it to view its details.
Invocations	The total number of invocations recorded for this connector.
Max time	The longest execution time recorded for this connector.
Failed	The number of failed invocations recorded for this connector.
Status	The connectivity status of the connector, for example All connected. See connectivity states for what each status means.

View outbound connector details

Select an outbound connector to view its details.

The page shows the connector name with badges indicating its direction (Outbound), whether it's enabled, and its connectivity status.

The page header shows counts for the selected connector:

Field	Description
Calls	The sum of all invocations across runtimes.
Total time	The sum of execution time for all invocations across runtimes.
Slowest call	The highest execution time recorded across runtimes.
Average time	The total time divided by the number of calls.

The Configuration section shows the connector's setup:

Field	Description
Input variables	The input variables used by the connector.
Timeout	The configured timeout for the connector. If none is set, this shows Not configured.

Outbound connector runtimes

The Connector runtimes section shows each runtime deployment reporting the connector, with its connectivity details and invocation metrics.

Field	Description
Connector runtime	The runtime deployment reporting the connector and its overall connectivity status, for example All connected.
Connectivity type	The connectivity reported for this runtime, for example Broker or Gateway, along with its status and number of streams.
Stream IDs	The stream IDs registered for this connectivity type. Select the copy icon to copy an ID.

Each broker or gateway connectivity type reports one of the following connectivity states:

State	Description
All connected	All client streams for this job type are registered as consumers on all broker remote streams.
Partially connected	Client streams exist on the gateway, but not all of them appear as consumers on every broker's remote stream. This can indicate a transient issue; if it persists, restart the gateway.
None	Brokers were queried, but no client stream appears as a consumer on any broker's remote stream. This indicates a genuine connectivity problem.
Unknown	The broker state can't be determined. This can happen when broker monitoring isn't configured; broker monitoring is configured but the query failed and the gateway's remote streams are also empty; or the gateway is a standalone deployment with no embedded broker. Enable and configure broker monitoring to get an accurate connectivity state.

Each runtime also shows its own invocation metrics:

Field	Description
Completed	The number of invocations completed on this runtime.
Cumulative time	The total execution time recorded on this runtime.
Slowest	The highest execution time recorded on this runtime.
Mean time	The average execution time recorded on this runtime.

Connector metrics

Connector metrics are available for inbound and outbound connectors.

For metric definitions, response fields, and endpoint details, use the connector observability reference.

Connector management access

Access to connector management depends on your cluster and organization permissions. If you cannot open connector management or view connector details, contact your administrator.
